After some serious tinkering, I was finally able to get my original Mac Plus (cira 1986) to surf the web natively. No cheating, no terminal emulation. Just a real web browser running in System 6 accessing the live internet.

Here’s what the System 6 Heaven webpage looks like on the Plus:

That’s not just a text file!  It’s actually MacWWW, an early web browser (circa 1992) that can run on System 6.  For comparison, here is the same webpage in Safari 5: <Photo Missing>

How did I do it?

Well, it was a little tricky since the Mac Plus and System 6 were built before the web, web browsers, home Ethernet LANs and always-on broadband Internet connections were common place (or in some cases even invented). Macs of that time communicated using AppleTalk over LocalTalk networks, both of which are obsolete and no longer even supported by contemporary Mac OS X.

First, I acquired a Quadra 700 for the lab (circa 1992), sort of the Mac Pro of it’s day, since it has ports that support both LocalTalk and Ethernet (using a proprietary Apple AAUI adapter, yes another trip to eBay) and can run System 7. After getting it working on both the modern Ethernet LAN and the vintage LocalTalk network with the Plus on it, the next step was to bridge the two networks using Apple’s (now freely available) LocalTalk Bridge software (the trick being to remember it will always use your printer port for LocalTalk!).

With that in place and working, I could now use AppleTalk file sharing across both networks to easily move all the vintage software around that I needed on the respective systems. It also occurred to me that I should back all this up, given the age of the hard drives and floppy disks, so after exploring open source alternatives like FreeNAS (and learning the vagaries of which versions of AppleTalk are supported by which OSes), I resorted to bringing up a virtual Windows NT 4 Server (cira 1994) with Services for Macintosh. It gave me quite the chuckle that I had to use a Microsoft product to pull this off.

Lastly, I made a clean System 6 install on the Mac Plus and added MacTCP but still needed to get TCP/IP routed over LocalTalk and the bridge on the Quadra. For that, I found IPNetRouter and these instructions which quite frankly required some serious trial and error (the trick there being while you set the bridging machine address as the gateway on the LocalTalk devices, you have to use a real DNS server address).

After some patient tinkering, and many disappointing pings on the Mac Plus, I got it working and fired up MacWWW to find a webpage with no graphics, JavaScript, CSS, Flash, embedded media, or just about any modern element we take for granted. You see the results in the pictures above.

Why did I do it?

Just to see if I could I suppose.

Both my Mac Plus and the early web played an important part in my life and the beginning of my career. I can still recall when NCSA Mosaic was first installed in the university computer lab–after just being told during orientation that most of us would work in jobs that hadn’t been invented yet (which has held true for me).  And aside from a brief (and shameful) period during the late 90’s, I’ve always had a Mac.

I had wanted to do this for some time, but it wasn’t until my recent focus on some other vintage technology projects that I got serious. My next task is to get a solid SSH client working on the vintage machines (perhaps for retro Twitter), as well as virtualizing each of them in emulators on my modern systems (so they can live in perpetuity).

Anyone up for a game of Bolo?
